Key Features
Sizes (mm) Standard Welding Position
View(+)Shielding gas Polarity 1.2~4.0 AWS A5.9
EN 14343 B
KS D 7026
JIS Z 3321ER309L
SS309L
Y309L
Y309LF, HF, H, VU, VD, OH Ar DC(-) Typical chemical composition of wire (%) C Si Mn P S Cr Ni Mo Remark 0.01 0.45 1.65 - - 23.09 13.78 0.08 - Typical mechanical properties of all-weld metal Y.S (MPa) T.S (MPa) EI. (%) Hardness (HV) IV (J) PWHT 430 590 42 - 110 (0℃) -
- Product Dimensions and Weld Current Range
Welding
PositionSizes (mm) Ampere (A) Volt (V) Min. Max. Min. Max. All Positon 0.9mm 50 80 10 12 All Positon 1.2mm 70 120 10 12 All Positon 1.6mm 90 170 11 16 All Positon 2.4mm 100 200 13 20 All Positon 3.2mm 120 250 13 22
