Key Features
Sizes (mm) Standard Welding Position
View(+)Shielding gas Polarity 2.0~5.0 KS D 7014
AWS A5.4
EN ISO 3581-A
EN ISO 3581-B
JIS Z 3221E316L-16
E316L-16
E 19 12 3 L R 12
ES316L-16
ES316L-16F, HF, H, VU, OH - AC/DC(+) Typical chemical composition all-weld metal (%) C Si Mn P S Cr Ni Mo Remark 0.03 0.75 0.80 0.028 0.011 17.95 11.71 2.60 - Typical mechanical properties of all-weld metal Y.S (MPa) T.S (MPa) EI. (%) Hardness (HV) IV (J) PWHT 390 570 43 - 40 (-120℃) -
- Product Dimensions and Weld Current Range
Welding
PositionSizes (mm) Ampere (A) Volt (V) Min. Max. Min. Max. F, HF 2.0mm 40 50 VU, OH 2.0mm 35 45 F, HF 2.6mm 55 70 VU, OH 2.6mm 45 60 F, HF 3.2mm 80 110 VU, OH 3.2mm 70 90 F, HF 4.0mm 120 150 VU, OH 4.0mm 90 130 F, HF 5.0mm 140 180
